Specifications

Frame
SMOOTHWALL™ Carbon frame with full sealed cartridge bearings, press-fit bottom bracket, and internal cable routing. Features 2-bolt ISCG05 tabs, RIDE-9™ adjustable geometry, and a 2-position rear axle. 140mm rear travel with a SMOOTHWALL™ Carbon rear triangle.

Fork
Fox 36 Float EVOL GRIP Performance Series, 150mm travel
• 27.5” models: 37mm offset
• 29” models: 44mm offset

Front Travel
150mm

Rear Shock
Fox Float DPS Performance with sealed bearing eyelet
• Hardware: 25x8mm F
• Shock sizing:
 – XS–SM: 190x45mm
 – MD–LG–XL: 210x52.5mm
• Size-specific tune (see FAQ)

Rear Travel
140mm

Headset
FSA Orbit NO.57E with sealed stainless bearings (36° x 45°)
• Upper: 30.2mm x 41mm x 7.1mm
• Lower: 40mm x 51.8mm x 7.5mm
• 1.5” crown race

Stem
Rocky Mountain 35 AM, 5° rise, 40mm (all sizes)

Handlebar
Rocky Mountain AM, 780mm width, 25mm rise
• 9° backsweep, 5° upsweep
• 35mm clamp diameter

Grips
ODI Elite Pro Lock-On

Brakes
Shimano SLX Trail 4-piston brakes with metal pads
• Rotors: Shimano RT66 180mm (front & rear)

Shifters
Shimano XT

Rear Derailleur
Shimano XT

Crankset & Chainring
Race Face Aeffect Cinch with 32T steel chainring
• 24mm spindle
• Crank lengths:
 – XS: 165mm
 – SM–XL: 170mm

Bottom Bracket
Shimano SM-BBMT500

Cassette
Shimano SLX 10–51T

Chain
Shimano M6100

Front Hub
Rocky Mountain sealed Boost hub, 15mm axle

Rear Hub
DT Swiss 370 Boost 148mm with 18T Star Ratchet

Spokes
DT Swiss Champion 2.0

Rims
WTB ST Light i30 TCS 2.0, 32H
• Tubeless-ready (tape and valves included)

Tires
• Front: Maxxis Minion DHF 2.5 WT, 3C MaxxTerra, EXO+, Tubeless Ready
• Rear: Maxxis Minion DHR II 2.4 WT, 3C MaxxTerra, EXO+, Tubeless Ready

Seatpost
Rocky Mountain Toonie Drop Alloy, 30.9mm
• XS–SM: 125mm
• MD: 150mm
• LG–XL: 170mm
