The DT Swiss XM 481 is a welded aluminum 29 in all mountain rim with a 30 mm inner width, tubeless ready, drilled for 32 spokes and disc brakes.

What it's for

This is a bare rim for building or rebuilding a 29 in mountain bike wheel. DT Swiss classes it as an all mountain rim, with a 30 mm inner width that gives tires more volume and sidewall support on the trail.

How it works

Welded joint: The rim ends are welded together instead of pinned or sleeved.

Hooked tubeless profile: The rim has bead hooks and is tubeless compatible.

PHR washers: The spoke holes have no eyelets. DT Swiss supplies PHR washers that sit under each nipple to spread the load on the rim bed.

Squorx nipples: The included Pro Lock Squorx aluminum nipples are driven from the rim side with a Squorx tool, and have thread locking compound in the threads.

Compatibility

• Wheel size: 29 in (622 mm bead seat, same as 700C)
• Brakes: disc only. There is no rim brake track.
• Spoke count: 32 hole. Your hub must also be 32 hole.
• Valve: Presta
• Electric bikes: approved by DT Swiss up to 32 km/h or 250 W
• Use rating: ASTM category 4
• Max system weight: 120 kg (rider, bike, and gear together)

Setup and installation

• ERD: 601 mm. Use this to calculate spoke length for your hub and lacing pattern.
• Washers: fit one PHR washer under every nipple.
• Tubeless: add tubeless tape and a tubeless valve.
• Wheel building: OMG's bike shop can calculate spokes and build the wheel.

Specs

• Size: 29 in
• Inner width: 30 mm
• Outer width: 35 mm
• Height: 21 mm
• ERD: 601 mm
• Holes: 32
• Weight: 550 g
• Material: aluminum
• Joint: welded
• Color: black

In the box

• XM 481 rim
• DT Pro Lock Squorx aluminum nipples, silver
• PHR washers

You will also need

• Spokes: 32, in lengths calculated for your hub
• Hub: 32 hole disc hub
• Tubeless tape and valve
• Squorx nipple tool
